Okm Fusion Professional

The metal detector and 3D floor scanner Fusion Professional is the revised and improved version of the metal detector Future 2018 Anniversary edition. It has been developed for beginners in the 3D metal location and offers advanced measurement functions in addition to simple handling.

The Fusion 3D ground scanner supports treasure hunters, gold seekers, adventurers and archaeologists in finding lost treasures, buried artefacts, hidden settlements and other historical objects and structures. Based on our Future 2018, the Fusion Professional has a robust design and is significantly lighter.

The metal detector Fusion Professional is especially suitable for beginners with a small budget.

Apply Fusion Professional

The OKM Fusion Professional is used exclusively in vertical alignment and supports the following operating modes:

• 3D Ground Scan: A graphic 3D floor measurement with detailed analysis on a computer. With 3D Ground Scan treasure hunters can visualize the structures and objects found in three-dimensional representations. Using the scan images, treasure hunters can determine the position, size and depth of target objects.
• Live sound: An acoustic magnetic field measurement for detecting ferromagnetic metals. With Live sound treasure hunters and archaeologists can track metal objects near the surface in real time. This mode is used to free the scanning field from interfering small metal objects before performing a 3D ground scan.

Find metal objects with the inductive SRIS search coil

One of the new locating functions is the SRIS search coil with which small metal objects near the surface can be detected. The SRIS search coil can be used particularly well as a pinpointer during the excavation. When digging, it can be difficult to determine the exact position of the smaller objects.

You can also find small objects such as:

• Wedding rings and earrings
• Brooch, bracelets and necklaces
• Coins
• Buttons, badges and plugs

Visualize buried treasures in 3D

During the measurement of an unknown area and the recording of measured values, the Visualizer 3D Software analyze this information at the same time and display hidden objects and structures as multicolored 3D graphics. As a result, you will see all buried treasures, gold objects, archaeological artefacts and other objects hidden in the background before the excavation.

In addition, you can determine the size, position and depth of the individual detected objects. In this way you know exactly where and how deep you have to dig to hit the coveted treasures.

Scope of delivery

Technical details

Control unit

• Dimensions (H x B x T): 950 mm, 65 / 80 mm
• Weight: approx. 1 kg
• Processor / Main CPU: Cortex M3, 32 MHz
• Processor / slave CPU: Cortex M0, 24 MHz
• Sample rate: 1024 values per second
• Measurement resolution: 16 bit
• Operating temperature: -10°C to 60°C
• Storage temperature: -20°C to 70°C
• Audio: Bluetooth Headphones
• Waterproof: No
• Humidity: 5% to 75%
• Protection type: IP40
• Sensor / coil technology: SCMI-15-D / SRIS-18K
• Input (for charger): 19 V DC / 3.16 A
• Operating time: approx. 12 hours (internal battery)
• Charging time: approx. 3 hours (internal battery)

Data transmission

• Technology: Bluetooth 5.1
• Frequency range: 2.402 – 2.480 GHz
• Maximum transmission rate: 1 Mbps
• Maximum transmission: +8 dBm
• Maximum range: approx. 10 m

Minimum requirements Computer

• Interface: USB 2.0
• Free space: at least 250 MB
• Memory (RAM): 2 GB
• Display: 1920 x 1080
• Processor: 1.2 GHz
• Graphic card: 1 GB RAM, OpenGL 3.3
• Operating system: Windows 10

Technical data are averages. During continuous operation, slight deviations are quite possible.
