Tero Vido 3D System Gold Detector Basic Plus Version

The Tero Vido 3D System – Precise Ground Detection

Discover precise ground anomalies with the Tero Vido 3D System. Perfect for metal and void detection, this portable device offers high-resolution imaging.

• Precise localisation of underground anomalies
• High-resolution imaging for accurate metal discrimination
• Multi-language user interface available in English, German, French, Russian, Arabic, Turkish, Spanish, Greek, Romanian and Bulgarian
• Automatic software updates with new languages and improvements

The Tero Vido 3D System is built extremely simple and can be used by anyone after only a short training period. It consists of the inconspicuous and lightweight ground scanner and a portable computer (tablet). No cables or heavy batteries impede the work with the machine. The user scans the ground with the sensor, and the scan results are shown in real-time on the computer screen. Immediately after finalising the measuring process the results can be analysed in the software. The data will be stored on the computer and can be retrieved when necessary.

The high resolution graphic, one of the best and most detailed resolutions on the market, along with the many options for adjustment in the software facilitate the quick detection of metal or void, and determine its depth and size. The system delivers repeatable results and a control scan will confirm the measuring result. You can also use the Tero Vido 3D System for metal discrimination and see if your find is made of ferromagnetic metals or non-ferromagnetic precious metals.

The Tero Vido 3D Systems is an all-purpose device and can be used on any ground condition, be it sandy, rocky or loamy. Small metal anomalies in highly mineralized grounds can be filtered with the software. Technical Data Basic Plus Version Tablet with pre-installed software Tero Vido 3D Sensor 1 – Vertical 85 cm Sensor 2 – Horizontal, 50 cm Carrying rod for horizontal sensor USB-Dongle for data exchange between sensor and computer Charging cable and adapter for USB – 12 V DC and 220 V AC Manual and Quick Start Guide Flexible tablet carrying case with touch-sensitive screen protection Solid transport box for sensors and tablet, Peli case – waterproof Headphones (Bluetooth/WiFi) Probes Sensors – 3-axis digital sensors Built-in rechargeable battery Type – LiPo rechargeable battery Performance – parameters 800 mAh 4,2V Internal operating voltage – 3,0V Battery run-time – 15h Charging time – 1h with mains adapter, 4h with in-car charger Charger Input voltage – 240/110 V or 12 V (in-car charger) Charging current – 5 V / 500 mA max. Measurement and weight of probes Horizontal probe 100: Length 100cm, Diameter 5cm, Weight 1,2kg Horizontal probe 50: Length 50cm, Diameter 5cm, Weight 0,5kg Vertical probe: Length 85cm, Diameter 5cm, Weight 0,8kg IP protection category – IP 54 (splash-proof) Storage temperature – -20° to +60°C Working temperature – -10° to +50°C Relative humidity – 5-95%, non-condensing Notifications – Multi-colour LED USB radio module for data transfer Frequency band – 2.4GHz ISM band Channels – 126 RF channels Transmission rate (air) – 2Mbps Programmable output – 0, -6, -12 or -18 dBm Sensitivity – -82 dBm Sensitivity at 2 Mbps Processor Microcontroller – 8-bit RISC-based Microcontroller Maximum working frequency – 16MHz 1KB SRAM, 512K EEPROM 10-bit A/D converter Data transfer (Bluetooth) Frequency range – 2,5 – 2,4835 GHz Maximum transfer rate – 1 Mbps Receiver sensitivity – -85 dBm Maximum reach in the open – Approx. 10 m Technical requirements for computer Operating system – Windows 8.1 or newer Disk drive – CD-ROM drive; alternatively: software download from company website USB – USB 2.0 or higher Bluetooth – For the Headphones Processor speed – 1 GHz Working memory – 1 GB RAM Disk space – HDD 250 MB Graphic card – DirectX9 compatible Certificates and warranty Technical certificates and 2 years warranty are standard for all Tero Vido 3D System ground scan devices. Before the goods are leaving our company, they are thoroughly tested by our engineers. That, and intense field tests and constant improvements make sure that we deliver continuously high quality and provide you always one of the professionals available on the market. We deliver tax free to private and business clients in countries outside the EU. Ask for options and quotes! We will help you to find the best detector for your needs!
